Structural Steel Design, Drafting, Detailing

Facility Capture has vast experience when it comes to creating a 3D model of existing structures and modifying them to meet changing requirements. No matter what the challenge, we are here to meet it. Pictured here is the steel structure of a bridge cable tower. We supplied the cover plate drawings matching thousands of threaded holes, verifying hole placement before installation using laser cut cardboard.
